Automatic Pharmaceutical Soft Double Aluminum Foil Tablet Strip Packing Machine
Automatic Pharmaceutical Soft Double Aluminum Foil Tablet Strip Packing Machine Quick Details:
1. PLC & Touch Screen Control
2. meet ISO, CE, GMP requirement
Automatic Pharmaceutical Soft Double Aluminum Foil Tablet Strip Packing Machine Features:
1. Innovative design which compared with old type
2. Each mechanism adopt independent power unit, servo drive, PLC control, to ensure synchronism and steady at high speed running
3. Material controlling adopt ratchet mechanism, servo drive, PLC control, can effective higher feeding speed to meet machine high speed running
4. The diameter of heat pressing cam can be changed between 90-130mm, easy to change different specification.
5. Heating thermometric parts adopt infrared checking, PLC control, can effective avoid bad sealing, virtual stick etc phenomenon which caused by temperature error at high speed running.
6. Product feeding adopt roll cutting feeding, servo drive, PLC control, can effective raise machine speed and ensure synchronism and steady.
7. Defective sorting, product transporting adopt manipulator control, convenient for follow-up connect line.
8. Waste material mechanism adopt roll cutting type, convenient for waste material recycle.
9. Machine without pneumatic component, no need compressed air.
10. This machine suitable for AL/PL laminated foil packaging, also suitable for Paper/Foil or thin film/thin plastic film package.
11. This machine design novel, beautiful, the cover consist of armoured glass and aluminum alloy frame to higher product level.
Main Technical Parameter
| Speed of drum | 5-11m/min |
| Packing Specification | 440 |
| PVC for medicine | 0.05-0.1*440mm |
| AL/PL Laminated Foil | 0.08*440mm |
| Electrothermal Power | 3.2kw |
| Main Motor Power | 1.55kw |
| Overall Dimension | 1800*1100*2100(L*W*H) |
| Weight | 1000kg |
Our Company:
STH is a professional manufacturer and supplier of pharmaceutical and food chemicals machinery and equipment in China.We have a well-experienced team to manufacture pharmaceutical machinery and equipments and a professional design institute. With rich experiences in pharmaceutical machinery and equipment field and numbers of professional engineers, we have designed and developed many types of machinery and equipments including tablet press machine, soft-gel production line, granulator, mixer, dryers, pulverizer, packaging machine,soft and hard blister packing machine, capsule filling machines, cartoner etc.
We made the Standard, we beyond it. Welcome you come to STH for visiting and guiding.
FAQ:
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request. Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Shanghai Chongming Island. Just let us know your scheduel in advance and we will arrange everything for you!
Any other doubts about our machine, please feel easy to contact with us.
